Dry-type transformer vacuum epoxy resin casting plant with Casting process for Epoxy resin

Ask Lasest Price
Brand Name :	JT-RESIN
Model Number :	888
Certification :	SGS，CE,UL
Price :	consult
Payment Terms :	T/T, Western Union, MoneyGram, D/P
Supply Ability :	100pcs/month
Delivery Time :	5 days

Add to Cart

Product Details
Company Profile

Dry-type transformer vacuum epoxy resin casting plant with Casting process for Epoxy resin

Basic Info.

Model NO.

KCB

Material Status

Solution, Strap

Drying Medium

Inactive Gas, Superheated Steam, Effluent Gas, Air

Operation Pressure

Vacuum

Operational Method

Continuous

Turn-Key Projects

One-Step Service

Standard

KCB Series Standard

Product Name

Vacuum Casting Equipment

Pouring Pot Size mm

2200X3000

Mixing Bowl

300L

Transport Package

Wooden

Specification

900*900*900

Trademark

Origin

China

HS Code

84292990

Production Capacity

60000PCS/Year

Product Description

My Company:
is a high-tech private enterprise, it has a experienced term, which more than ten years engaged in research and development, design, manufacture and installation of vacuum equipment. Besides, it is not only committed to build high quality brand about vacuum equipment, but it also has prodcuts, which are widely used in impregnating, epoxy resin pouring, drying, and note oil processing in some industries(like metal heat treatment, transformer, and transformer device, reactor device, reg- ulator device, high pressure electrical, motor, capacitor, switch and other similar industries).
Relying on strong technical advantages and scale advantages, and it also dedicated itslef to develop Vacuum application technology and relative vacuum equipment Main products are differnent kinds of vacuum casting equipments, vacuum drying equipment, vacuum impregnation equipment, vacuum oiling device equipment, and vacuum heat treatment equipment.
The most important of this company is product qualitu, and it strictly follows international quality certification system, implmentcation od quality poliy about'creating a Kerry brands, buliding first-class equipment, following innovation for development, and being in accordance with customer service.It also provides the best solution, higher quality products and more valuable and efficient after-sales service for
new and old customers.

Overview
KC Series of epoxy resin vacuum casting equipment is mainly used for dry-type transformers, dry-type casing, dry-type current transformers, dry-type transformers, high-voltage switch insulation, arc and other electrical products of epoxy resin
casting production.
Our company has been committed to the pouring process, equipment research and development, technology in the domestic leading position. My company has an experienced design, manufacturing, installation, commissioning, trial production one of the technical team.
1 ,This series equipment used in electrical products with fillers and pouring;
2 ,This series equipment is suitable A Epoxy resins, UV-outdoor-type epoxy resin and polyurethane vacuum degassing, a combination of polymer materials and casting, for both foreign and domestic production of resin used.
3 ,This series of products can be used for user-filled hybrid and two-component mixed fillers, with great flexibility.
4 ,This series based on user demand, to increase or decrease the equipment
system, modular Assembly option. Easy to install a high degree of automation and easy to master.
KC Series casting equipment are:
KCB Series standard vacuum casting equipment
KCY Series of standard vacuum pressure casting equipment
KCD Series of electronic measurement of vacuum pressure casting plant
KCJ Series of static mixing vacuum pressure casting plant

Main technical characteristics
1,By vacuum casting system, equipment, vacuum mixing system, two sets of electric heating system, two sets of condensing system, two
independent vacuum system.
2 ,Using thin film degassing, mixing tank, inverter suitable for different viscosity of resin.
3 ,Filters, two sets of condensation is our independent research and
development of double filtration filters effectively protect the vacuum pump.
4,Pouring cans of clean, energy-efficient heating systems, mixing bowl steady heat conduction oil heating system is adopted.
5,Analog screen +PLC Control, stable and reliable, and can be equipped with touch-screen system
6 , And two sets of vacuum system on mixing bowl , pouring cans , independence air and high efficie

Technical parameters Dry-type transformer vacuum epoxy resin casting plant with Casting process for Epoxy resin

Dry-type transformer vacuum epoxy resin casting plant with Casting process for Epoxy resin

NO	Model	mm Pouring pot size mm	Mixing bowl	Vacuum unit(a)	Vacuum unit(a)	Working pressure	Measurement	Control mode
1	KCB-300-2200	2200X3000	300L	2X-70/ZJY-300	2X-30	Atmospheric pressure	Manual	rocn screen
2	KCB-300-2400	2400X3000	300L	2X-70/ZJY-300	2X-30	Almospherite presure	Manual	Touh sreen
3	KCB-400-2400	2400X3000	400L	2X-70/ZJY-300	2X-30	Atmospheric pressure	Manual	Touen screen
4	KCB-400-2600	2600X3000	400L	2X-70/ZJY-300	2X-30	Almospheric pressure	Manual	Analo screen
5	KCB-500-3000	3000X3500	500L	X-100/ZJY-600	2X-70	Atmospheric pressur	Manual	rocn screen
