    JT2252 Vacuum Casting Process for Instrument Transformer

    Ask Lasest Price
    Brand Name : JT-RESIN
    Model Number : JT2252
    Certification : SGS,CE,UL
    Price : $3/kg
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 200Ton/week
    Delivery Time : 5 days
    • Product Details
    • Company Profile

    JT2252 Vacuum Casting Process for Instrument Transformer

    Wholesale casting resin and liquid epoxy resin (NPEL_9225) and Electrical insulation epoxy resin for molds and transform

    Product Description

    Indoor electrical insulation parts for medium and high voltage equipment ,such as switchgears and electrical components.Encapsulation of large metal parts.Recommended for application with long term stresses up to service temperature of 85℃.


    Liquid ,hot-curing casting resin system with high glass transition temperature for producing casting insulation parts with excellent mechanical end-properties and very high thermal shock resistance.

    Epoxy resin
    JT2252A
    100pbw
    Hardener
    JT2252B
    100pbw
    Filler
    Silica flour
    340-380pbw
    Color paste
    JT009
    3pbw

    JT2252 Vacuum Casting Process for Instrument TransformerJT2252 Vacuum Casting Process for Instrument TransformerJT2252 Vacuum Casting Process for Instrument TransformerJT2252 Vacuum Casting Process for Instrument Transformer

    Vacuum casting process of instrument transformer


    Resin model:

    Resin/ Hardener / Silica powder = XXX : XXX : XXX (pbw)


    1) Material Pouring:

    JT2252 Vacuum Casting Process for Instrument Transformer

    JT2252 Vacuum Casting Process for Instrument Transformer


    2) Curing


    1. Initial Gelatin:8h@80 °C + 2h@100 °C+ 6h@130°C;

    1. Demould:Act slightly, try to shorten the demould time, after demoulding, put the casting parts into the oven within 5minutes, and cooling with the furnace

    1. Taking out of furnace:cooling to below 40 °C before taking casting parts out of furnace

    3) Remark

    This process is for reference only, the exact one should be adjusted as per the casting parts and casting equipment.

    JT2252 Vacuum Casting Process for Instrument Transformer

    JT2252 Vacuum Casting Process for Instrument TransformerJT2252 Vacuum Casting Process for Instrument Transformer
