Mould Cleaning Agent for High voltage power APG and mixer for pouring equipment

MSDS:

1. IDENTIFICATION

Commodity name: JT6300 cleaning liquid

Recommended use of the chemical and restrictions on use: For industry use only.

Company Name: HUBEI JIANGTE INSULATION COMPOSITE CO., LTD.

Add: No.219, Zhanghua Rd(N), EDA of Qianjiang City, Hubei Province, China

Tel:+86-728-6201068

Fax:+86-728-6202066

Zip code:433132

2. HAZARDS IDENTIFICATION

HEALTH HAZARDS

Irritating to skin

Harmful: may cause lung damage if swallowed

Vapours may cause drowsiness and dizziness

ENVIRONMENTAL HAZARDS

Toxic to aquatic organisms, may cause long term adverse effects in the aquatic environment

PHYSICAL AND CHEMICAL HAZARDS/FIRE AND EXPLOSION HAZARDS

Extreme hazard. Leaks of gas or spills of liquid can readily form flammable mixtures at temperatures at or above the flash point

Static discharge. Product can accumulate static charges which can cause an incendiary electrical discharge

3. COMPOSITON INFORMATION ON INGREDIENT

4. FIRST AID MEASURES

INHALATION

- Using proper respiratory protection, immediately remove the affected victim from exposure. Administer artificial respiration if breathing is stopped. Keep at rest. Call for prompt medical attention.

SKIN CONTACT

- Flush with large amounts of water; use soap if available

- Remove grossly contaminated clothing, including shoes, and launder before reuse

EYE CONTACT:

Flush eyes with large amounts of water until irritation subsides. If irritation persists, get medical attention

INGESTION:

-If swallowed, do not induce vomiting. Keep at rest. Get pro,pt medical attention.

5. FIRE-FIGHTING MEASURES

FIRE FIGHTING PROCEDURES:

-Use water spray to cool fire exposed surfaces and to protect personnel. Shut off” Fuel” to fire. If a leak or spill has not ignited, use water spray to disperse the vapors and to protect men attempting to stop a leak

-Either allow fire to burn under controlled conditions or extinguish with foam or dry chemical.

Try to cover liquid spills with foam.

SPECIAL FIRE PRECAUTIONS:

-Avoid spraying water directly into storage containers due to danger of boilver

-See also Section 4” FIRST AID MEASURES” as well as Section 10 “ STABILITY AND REACTIVITY”

HAZARDOUS CPMBUSTION PRODUCTS:

No unusual

6. ACCIDENTAL RELEASE MEASURES

LAND SPILL:

-Eliminate sources of ignition. Warn occupants of downwind areas of fire and explosion hazard. Prevent liquid from entering sewers, watercourses, or low areas.

-Keep public away, Shut off source if possible to do so without hazard.

Advise authorities if substance has entered a watercourse or sewer or has contaminated soil or vegetation. Take measures to minimize the effect on the ground water.

- Contain spilled liquid with sand or earth

-Recover by pumping( use an explosion proof or hand pump) or with a suitable absorbent. If liquid is too viscous for pumping, scrape up with shovels or pails and place in suitable containers for recycle or disposal.

-Consult an expert on disposal of recovered material and ensure conformity to local disposal regulations.

- See Section 4” FIRST AID MEASURES” as well as Section 10” STABILITY AND REACTIVITY”

7. HANDLING AND STORAGE

STORAGE TEMPERATURE(Degc): Ambient

TRANSPORT TEMPERATURE(DegC): Ambient

LOADING/UNLOADING TEMPERATURE(DegC):

VISCOSITY(cSt): 0.90

STORAGE/TRANSPORT PRESSURE(kPa): Atmospheric

ELECTROSTATIC ACCUMULATION HAZARD

Yes, use proper grounding procedure

USUAL SHIPPING CONTAINERS:

Tankers, rail wagons, tank trucks, drums

MATERIALS AND COATINGS SUITABLE:

Carbon Steel

Stainless Steel

Polyethylene

Polypropylene

Polyester

Teflon

MATERIALS AND COATINGS UNSUITABLE:

Natural Rubber

Butyl Rubber

EPDM

Polystyrene

Compatibility with plastic materials can vary; we therefore recommend that compatibility is tested prior to use.

STORAGE/HANDING, GENRAL NOTES

-Keep container closed. Handle containers with care. Open slowly in order to control possible pressure release. Store in a cool, well-ventilated place away from incompatible materials.

-Do not handle, store or open near an open flame, sources of heat or sources of ignition. Protect material from direct sunlight.

-Material will accumulate static charges which may cause an electrical spark(ignition source). Use proper bonding and/ or grounding procedures.

-Do not pressurize, cut, heat, or weld containers. Empty product containers may contain product residue. Do not reuse empty containers without commercial cleaning or reconditioning.

ADDITIONAL WARNINGS

Containers remains hazardous when empty. Continue to observe all precautions.

8. EXPOSURE CONTROLS/PERSONAL PROTECTION

ENGINEERING CONTROLMEASURES/VENTILATION

The use of mechanical dilution ventilation is recommended whenever this product is used in a confined space, is heated above ambient temperatures or otherwise to maintain ambient concentration below the recommended threshold exposure limits. Use explosion-proof ventilation equipment.

OCCUPATIONAL EXPOSURE LIMITS

Exxonmobil recommends, for total hydrocarbons, based on composition and using the Reciprocal Calculation Procedure(RCP):

Alkanes, C7-C10-ISO;

TWA: 1400mg/m3(281ppm), ExxonMobil(2000).

This product contains the following components with a recognized or recommended OEL value:

Octane:

TAW: 300 ppm(1400mg/m3), ACGTH(2002)

PERSONAL PROTECTION

GENERAL ADVICE

The use and choice of personal protection equipment is related to the hazard of the product, the workplace, and the way the product is handled.

In general, we recommend as a minimum safety precaution that safety glasses with side-shields and workclothes protecting arms, legs and body be used. In addition, any person visiting an area where this product is handled or processed should at least wear safety glasses with side-shields.

SPECIAL ADICE

Based on and limited to ExxonMobil’s experience of this product as such the following special advice is believed to provide satisfactory protection for the industrial user or handler

RESPIRATORY PROTECTION

Where concentrations in air may exceed the limits given in this section, it is recommend to use a half face filter mask to protect from overexposure by inhalation. Suitable filter material depends on the amount and type of chemicals being handled in the workplace, but filter material of type“A”or similar may be considered for use.

HAND PROTECTION

When handling this product, it is recommended to wear chemical resistant gloves. The choice of suitable protective gloves depends on work conditions and what chemicals are handled, but we have positive experience with gloves made of Nitrile. Gloves should be replaced immediately if sign of degradation is observed.

EYE PROTECTION

See general advice

SKIN/BODY PROTECTION

See general advice

SKIN/BODY PROTECTION

See general advice

9. PHYSICAL AND CHEMICAL PROPERTIES

These are indicative values only. Please refer also to the product specification sheet.

9.1 General information

PHYSICAL STATE: liquid

FORM/COLOUR: Clear colourless liquid

ODOR: Isoparaffinic hydrocarbon odour

FREEZ/MELT/POINT: -62.78 DegC ASTM D97 (Pour Point)

BOILING POINT RANGE: between 115 and 138.89 DegC ASTM D1078

VAPOR PRESSURE( 20 degC): 2.15 Kpa Estimate

DENSITY(101.3 kPa/air=1): >4.10

VISCOSITY (25 DegC): 0.85 mm2/s ASTM

EVAPORATION RATE(n-Bu Acetate=1): 1.850

9.2 Health, Safety& Environmental Information

Flashpont(TCC ASTM D56): 7 DegC Typical

AUTOIGNITION TEMPERATURE: 395 DegC

EXPLOSIVE LIMITS( in air):

Between 0.9 abd 6.2 Vol%

SOLUBILITY IN WATER(20 DegC): <0.10 Wt%

9.3 Other Information

MOLECULAR WEIGHT: 118 Average

COEFF OF THERMAL EXPANSION(Liq): 0.00085 Vol/vol/deg C

IS MATERIAL HYGROSCOPIC: No

10. STABILITY AND REACTIVITY

HAZARDOUS POLYMERIZATION? No

CONDITIONS TO AVOID POLYMERIZATION:

Not Applicable

STABILITY: Stable

CONDITIONS TO AVOID INSTABILITY:

Not Applicable.

MATERIALS AND CONDITIONS TO AVOID(INCOMPATIBILITY)

Strong oxidizing agents

HAZARDOUS DECOMPOSITION PRODUCTS:

None

11. TOXICOLOGICAL INFORMATION

ACUTE:

INHALATION:

-High vapor/aerosol concentrations(greater than approximately 700ppm, attainable at elevated temperatures well above ambient) are irritating to the eyes and the respiratory tract, and may cause headaches, dizziness, anaesthesia, drowsiness,unconsciousness, and other central nervous system effects, including death.

SKIN CONTACT:

-Frequent or prolonged contact may defat and dry the skin, leading to discomfort and dermatitis.

-Low order of toxicity

-

EYE CONTACT:

-Will cause eye discomfort, but will not injure eye tissue

INGESTION:

-Small amounts of liquid aspirated into the respiratory system during ingestion or from vomiting may cause bronchopnbeumonia or pulmonary edema.

- Minimal toxicity

Additional information is available on special request

12. ECOLOGICALINFORMATION

ENVIRONMENTAL MOBILITY

This product is highly volatile and will rapidly evaporate to the air if released to the water

ENVIRONMENTAL DEGRADABILITY

Based upon data for a smilar component or preparation, or estimated data.

This substance is expected to biodegrade at a moderate rate and be “inherently” biodegradable according to OECD guidelines.

ECOTOXICITY AND BIOACCUMULATION

Expected to be toxic to aquatic organisms

Long term adverse effects to aquatic organisms are possible if continuous exposure is maintained.

13. DISPOSAL CONSIDERATIONS

The following advice only applies to the product as supplied.

Combination with other materials may well indicate another route of disposal. If in doubt, contact the local ExxonMobil affilite or local Authorities.

Empty packaging should be taken for recycling, recovery or disposal through a suitable qualified or licensed contractor.

Care should in any case be taken into ensure compliance with national and local regulations.

This product is NOT suitable for disposal by either landfill or via municipal sewers, drains, natural streams or rivers.

This product is ashless and can be burned directly in appropriate equipment

14. TRANSPORT INFORMATION

LAND

CLASS: 3 PG:II UN NUMBER:3295

HAZCHEM CODE: 3WE SUBSIDIARY RISK:

TRANSPORT DOCUMENT NAME:

HYDROCARBONS,LIQUID, N.O.S.(Isooctanes & Isononanes), CLAS3, UN 3295, PG II,( 7 Deg C )

AIR(ICAO/IATA)

CLASS: 3 PG: II UN NUMBER: 3295

PROPER SHIPPING NAME:

HYDRICARBONS, LIQUID, N.O.S.(Isooctanes & Isononanes)

15. REGULATORY INFORMATION

CLASSIFICATION AND LABELLING ACCORDING TO EC DIRECTIVES

CLASSIFICATION/SYMBOL: HIGHLY FLAMMABLE/F

CLASSFICATION/SYMBOL:DANGEROUS FOR THE ENVIRONMENT

GOVERING DIRECTIVE:

Dangerous Substance Directive 67/548/EC, as modified.

NATURE OF SPECIAL RISK

R11 Highly flammable

R38 Irritating to skin

R51/53 Toxic to aquatic organisms, may cause long term adverse effects in the aquatic environment

R65 Harmful: may cause lung damage if swallowed

R67 Vapour may cause drowsiness and dizziness

SAFETY ADVICE

S09 Keep container in a well ventilated place

S16 Keep away from sources of ignition-No smoking

S23 Do not breathe gas/fumes/vapour/spray

S24 Avoid contact with skin

S33 Take precautionary measures against static discharges

S43A In case of fire use sand, earth,chemical powder or foam

S57 Use appropriate container to avoid environmental contamination

S60 This material and/or its container must be disposed of as hazardous waste

S62 If swallowed, do not induce vomiting: seek medical advice immediately and show this container or label

16. OTHER INFORMATION

A. Reference

- The information contained herein is believed to be accurate. It is provided independently of any sale of the product for purpose of hazard communication. It is not intended to constitute performance information concerning the product. No express warranty, or implied warranty of merchantability or fitness for a particular purpose is made with respect to the product or the information contained herein.

B. Last date revised

- 2017-01-10

C. Other

- This SDS is prepared according to the Globally Harmonized System (GHS).

TDS:

Performance parameters:

Product Description:

JT 6101 Organic Silicon Mould Release agent

Features:

Good release effect

high stability

No reaction with the casting material

Not corrode the mold

Environment protection and without pollution

Process:

1. Remove grease and wax thoroughly with solvent to ensure the mould cavity clean and dry

2. For the new mould, initial using need to spray for 3-4times(After the solvent evaporation and then spray brush again),after that one mould to spray one time or several moulds to spray one time(several moulds to spray one time: normally paint one time after the mould poured 2～10 times)

3. When a thin coating can be formed on the surface of the mold cavity by the method of spraying or brushing, then it is ok

Packing:

5KG/ pot,20kg/drum

Storage:

Products need to be stored in a dry and ventilated environment with 18-40℃, and the shelf life is 1 year

Hubei Plant and Guangdong plant:

ISO certificate:

Part of our customers:

FAQ:

1. We’re using Huntsman epoxy resin, can I use JiangTe resin?

Yes,ours are equivalent to Huntsman. Please tell the number of Huntsman you’re using, we’ll offer the one matching.

2. What’s the pot life?

Pre-filled resin is one year; Pure resin is 2-3 years.

3. We’re just starting producing. Can you help us on the process?

No problem, we’ll offer guidance and support. We have thousands of customer manufacturers in China and overseas.

So we have good experiences.

Introduction

Established in 1998, Jiangte Insulation Composite Co., Ltd is high-tech enterprise engaging in the development, production and sale of electrical epoxy resin.

After more than 30 years of efforts, JiangTe has introduced a variety of electrical epoxy resin products which have been widely used in the manufacturing of dry type transformers, instrument transformers, medium to high voltage insulation parts and solid switchgears.

To provide the very best service, Jiangte has set up two production plants in Hubei and Guangdong producing more than 50 electrical epoxy resin line with an annual capacity exceeding eighty thousand (80000) tons. JiangTe is the most professional and the leading manufacturer of electrical epoxy resin in China.

JiangTe's two plants have received the ISO9001 quality system certification and ISO14001 environmental management system certification and are careful to meet all local and international health, environment and safety standards.

Additionally , JT has established a comprehensive Research and Development Center with a large selection of advanced testing equipment for their highly skilled research and production teams.
